P320 Emergency Ballast

Fluorescent Emergency Ballast with Quick Disconnect for Simple Replacement

By Iota

  • Overview
  • Specifications
*** Coming Soon ***
The IOTA P320 is a UL Listed fluorescent emergency ballast that allows the same fixture to be used for both normal and emergency operation. In the event of a power failure, the P320 switches power from the normal AC ballast and operates one or two of the existing lamps for up to 90 minutes in the emergency mode from the P320 battery supply. The unit contains a battery, charger, and inverter circuit in a single enclosure for installation within the wireway or on top of the fixture (RME1 accessory required for top mounting.) The P320 features a plug and port connector system for quick and easy end-of-life replacement without rewiring.
Initial Lumen Output
  • 1450 Lumens
Lamps Operated
  • (1 or 2) 2-4 ft. Bipin HO T8
  • (1 or 2) 32W T8 U-Bend
  • (1) 2-4 ft. 14W-54W T8
  • (1) 8 ft. Bipin HO T8
  • (1) 4-Pin 13W-42W Compact
Features
  • Reduced profile design is ideal for smaller ballast compartments
  • Plug and Port Connector System for easy end-of-life replacement with no wiring
  • Direct fit and function replacement for PSQ1400QD Emergency Ballast
  • Will cold start and operate all specified lamps
  • Long life, high temperature, recyclable Ni-Cad battery
  • Durable UL-94V-0 rated thermoplastic housing resists impact, scratches, and corrosion
  • Includes single piece test switch and charge indicator accessory kit
  • For use with switched or unswitched fixtures
  • Lamp selector switch optimizes light output for desired lamp type
  • Rated for use in enclosed and gasketed fixtures
  • Meets or exceeds all NEC and Life Safety Code Emergency Lighting Requirements
Read More
Read Less
Product Type Emergency Ballast
Voltage Rating 120-277
Frequency 50/60HZ
Max. Operating Temp. 38
Min. Operating Temp. 0
Battery Run Time 90 min
Battery Chemistry Type NiCd
Battery Recharge Time 24 hours
Battery Activation Unit Connector
Life Safety Testing Manual Testing
Regulatory Listing UL
Series P320
