DLS UI 27V 40A PFC Converter and Charger

40 Amp Power Converter and Battery Charger for 24V battery charging featuring Power Factor Correction

By Iota

  • Overview
  • Specifications
The DLS UI 27V 40A PFC Power Converter/Battery Charger from IOTA converts nominal 120-240 AC voltage to 27.2 DC voltage.

As a power supply, the unit's tightly controlled regulation allows the user to operate a nominal 24VDC load up to 40 amps.

As a battery charger, the unit will maintain the battery, delivering its full-rated current when the battery capacity falls sufficiently low. The voltage is set to deliver its maximum current for the necessary period of time to minimize undue stress to the battery caused by heating of its cells. This helps to ensure the longest possible life of the battery. Over time, as the battery nears its full capacity, the DLS will automatically drop the current, providing a float-charge to the battery to prevent self-discharge of the cells.

The unit features a Power-Factor Correction (PFC) design, providing efficient utility consumption and allows operation of the unit from a standard 15A circuit.
Input Voltage
  • 108-264 VAC
Input Frequency
  • 47-63 Hz
Output Voltage
  • 27.2 VDC
Output Amperage
  • 40 Amps
Read More
Read Less
Product Type Charger/Power Converter
Voltage Rating 120, 220-240
Frequency 50/60HZ
Load Voltage Rating 24VDC
Amperage 40
Max. Operating Temp. 40
Min. Operating Temp. 0
Regulatory Listing Not Applicable
Compliance Listing ROHS
Series DLS
