ILBLP CP30 HE SD HV

LED EMERGENCY DRIVER

Description
The IOTA ILBLP CP30 HE SD HV is a UL Listed emergency LED driver for field and factory installation that allows a fixture with 55-250VDC Non-Class 2 LED lighting loads to be used for both normal and emergency operation. In the event of a power failure, the ILBLP CP30 HE SD HV switches to the emergency mode and operates the existing fixture for 90 minutes. The unit contains a battery, charger, and converter circuit in a single enclosure with the option of either single or dual flexible conduit for wiring to the fixture and test accessories. The ILBLP CP30 HE SD HV will operate the 55-250VDC LED load at 30 watts with Constant Power. The patented Constant Power design of the unit maintains the rated output wattage to the LED array even as the battery voltage diminishes, resulting in a constant illumination level for the entire emergency runtime. Features lithium battery technology for significantly decreased form factor and includes automatic monthly and annual self-testing features as standard. Self-diagnostic status is communicated via the illuminated single-piece test accessory, which can be mounted up to 25 ft. from the unit.
Specifications

Input Voltage

(Universal) 120-277VAC, 50/60Hz

Input Current (120V/277V)

0.55A (nom. charging)

Output Voltage

50-250VDC (nom)

Output Current

0.12A (@200VDC) to 0.545A (@55VDC)

Output Power

30 Watts (constant)

Max. AC Driver Neutral Current

(120Vac) 5 Amps
(277Vac) 3 Amps

Power Factor

≥ 0.99*

Surge Protection

Meets or Exceeds ANSI/IEEE C62.41.2-2002

Emergency Operation

90 minutes

Operating Temp

0° to 55° C

Battery

Maintenance-free LiFePO4 Lithium Iron-Phosphate (no heavy metals)
24 Hour Recharge
5-7 Year Life Expectancy

Weight

(single flex) 4.4 lbs.
(dual flex) 5.5 lbs.

Certifications

cUL Listed for both Factory and Field Installation
CA T20 Appliance Efficiency Database
find the UL Mark on this productFind the California Title 20 BC Mark on this product

*PF ≥ 0.9 at 277Vac.

Advantages and Features

Product Advantages

  • Auto-Sensing Non-Class 2 Output
    Auto-adjusting 55-250 VDC output range accommodates a wide range of Non-Class 2 forward voltage designs.
  • Constant Power Performance
    Constant wattage delivery maintaines illumination for the full emergency runtime with no degradation.
  • Self-Diagnostic / Self-Testing
    Monthly and annual self-testing feature satisfies the periodic testing requirements in accordance with NFPA 101 while the on-board diagnostics provides system readiness with visual indicators.
  • High Output for Increased Illumination
    30W emergency output is ideal for elevated mounting heights and high-bay fixtures.
  • Certified for CA Title 20
    High Efficiency Performance meets CA Title 20 energy efficiency standards for small battery chargers.

Features

  • UL 924 Listed for U.S. and Canada
  • Two flexible conduit options for wiring to the fixture
  • AC-Activate circuity simplifies wiring by eliminating the need for manual battery connection during installation
  • Maintenance-free, high-temp recyclable LiFePO4 for significantly reduced space requirements
  • Durable, galvanized steel enclosure
  • Single-piece test switch and charge indicator can be remote-mounted up to 25 ft
  • For use with switched or unswitched fixtures
  • 5-year warranty. See Warranty Page for details.
  • Meets or exceeds all NEC, IBC, and Life Safety Code Emergency Lighting Requirements
  • Suitable for use in plenum and damp location applications
  • RoHS Compliant

Emergency Lumen Performance

Luminaire Efficacy Minute 1 Minute 45 Minute 90
100 lumens/watt 3000 3000 3000
110 lumens/watt 3300 3300 3300
120 lumens/watt 3600 3600 3600
130 lumens/watt 3900 3900 3900
140 lumens/watt 4200 4200 4200
150 lumens/watt 4500 4500 4500
Sample Specification
Click to Expand
Dimensions

Length: 17.81" (452mm)

Width: 2.26" (57mm)

Height: 2.05" (52mm)
