IOTA IIS 550 HE
Dimensions - IIS 550 HE - Length: 19.75in, Width: 11in, Height: 22in

IIS 550 HE Emergency Inverter

550 Watt, High Efficiency Emergency Inverter for CA Title 20

by Iota

The IOTA IIS 550 HE is a UL Listed stand-alone pure sine wave output inverter designed to provide power to designated emergency lighting fixtures. In a power loss situation, the IOTA IIS 550 HE will supply 550 watts of emergency power from the onboard battery supply. The IOTA IIS 550 HE works in conjunction with incandescent, LED, and fluorescent lamp and fixture types and will automatically run switched, normally-on, or normally-off designated emergency fixtures. The IIS 550 HE is ideal for applications that utilize multiple lamp and fixture types. The IOTA IIS 550 HE features increased inrush capability to prevent shutdown caused by inrush currents, allowing operation of loads at the full rated output of the unit with no need for circuit de-rating. The IIS 550 HE is designed for high-efficiency performance and is certified in the CA Title 20 Appliance Efficiency Database.
Load Capability
  • 550 Watts
Compatible Load Types
  • LED
  • Fluorescent
  • Incandescent
Features
  • High Efficiency Performance meets CA T20 battery charger efficiency standards
  • Operates load to its fully-rated capacity. Inrush capability eliminates need for circuit de-rating
  • Dimming relay for 0-10V dimming applications
  • Pure sine wave output
  • Includes dual-purpose momentary contact test switch and red charging indicator
  • Variable-rate, temperature compensated charger
  • Valve Regulated Lead Acid (VRLA) battery provides long life and is maintenance free
  • Line voltage allows for remote mounting of emergency fixtures at distances up to 1000 feet
  • Low Battery Voltage Disconnect and Line Latch Protection
  • Allows for emergency operation of switched and unswitched fixtures
  • Meets or exceeds all NEC, IBC, and Life Safety Code Emergency Lighting Requirements
  • Durable 16-gauge steel housing design with white semi-gloss powerder-coat paint finish
  • RoHS Compliant
  • Suggested Replacement Products

  • Spec Sheets

    Document Type Document Title Description Updated View
    {{document.DocumentType}} {{document.DocumentTitle}} {{document.Description}} {{document.UpdatedDate | date: 'MM/dd/yy'}} View
  • Photometry & Revit (BIM)

  • Specifications

    Battery Chemistry Type Lead Acid
    Load Voltage Rating 120VAC, 277VAC
    Battery Run Time 90 min
    Brand IOTA
    Environment Indoor
    Frequency 60HZ
    Regulatory Listing UL
    Maximum Operating Temperature 30
    Minimum Operating Temperature 20
    Output Power 550 Watts
    Product Type Emergency Inverter
    Series IIS
    Voltage Rating 120-277
