IISC Series Compact Inverter Systems

1000W to 2800W Inverters with Compact Cabinet

By Iota

  • Overview
  • Specifications
The IOTA IISC Inverter Systems are UL Listed single-phase sine wave output inverters designed to supply 1.0kVA to 2.8kVA of emergency power to the connected load. IISC Inverters will operate the emergency load at full brightness with a transfer speed of 2 milliseconds and feature a compact cabinet design to accommodate installations with limited space.
Emergency Operation
  • 1.0kVA to 1.8kVA
  • Operates all lighting load types
  • 120VAC to 277AC Input/Output Voltage options
Product Advantages
  • Single-phase emergency system with exceptional 98% power efficiency
  • Compact cabinet design with minimal 10.5 x 24.25 inch footprint
  • Fast Transfer (2 milliseconds) speed allows for uninterrupted operation of all lighting loads
  • Provides full light output in the emergency mode
  • Conducts required monthly and annual testing
Features
  • UL 924 Listed
  • PWM/IGBT inverter design for optimal switching speed
  • Micro-processor controlled, temperature-compensating charger
  • Sealed long-life maintenance-free VRLA batteries
  • Low Battery Voltage Disconnect protects the batteries against deep discharge
  • Includes Input Circuit Breaker and Battery Protection
  • User Programmable / Password Protected Interface
  • High-contrast VFD display screen
  • Includes RS232 Serial Communications port
  • Durable steel cabinet design with white finish
  • Forced air cooling only while in the emergency mode with no filter requirement
  • Meets or exceeds all NEC and Life Safety Code Emergency Lighting requirements
  • Covered by IOTA's standard 1-year warranty
  • Factory Startup and Training available
Read More
Read Less
Product Type Emergency Inverter
Voltage Rating 120, 208, 240, 277
Frequency 60HZ
Load Voltage Rating 120VAC, 208VAC, 240VAC, 277VAC
Output Power 1000 VA
Max. Operating Temp. 40
Min. Operating Temp. 0
Battery Run Time 90 min
Battery Chemistry Type Lead Acid
Life Safety Testing Self Diagnostics, Self Test
Regulatory Listing UL
Series IISC

Read More Read Less
